820 cm3 wheel motors (or optional 1260 cm3) give GT3 high-clearance capability even in the most difficult conditions. An automatic mode automatically adjusts the transmission so that you always benefit from the best possible gradeability.
GT3 offers the convenience of a self-propelled machine in a towed package, with a large 8.4" touch screen and a modern, intuitive multifunction joystick for setting and managing harvesting parameters. These features make machine management simple and precise. Cutting-edge on-board technology supports the winegrower during operation, making it easy to set up and operate the machine.
GT3 offers optimum work quality, both in terms of work rate and respect for the vines. Its long harvesting head, equipped with two shaker supports and a large flake train, allows it to work at high speed. A record storage capacity means you can work for long periods without having to empty. ARC² shakers ensure that the trellising is respected and that the berries are completely unhooked. Gentle, efficient cleaning is provided by vacuum cleaners. For complete sorting, the machine can also be fitted with the optional EASYclean integrated sorter, which ensures thorough de-stemming and cleaning of the harvest without trituration.
Numerous access points have been positioned around the GT3 to facilitate cleaning and maintenance. A large platform provides access to the machine's upper components for total maintenance in complete safety. A remote control allows tools or buckets to be operated from the ground without having to return to the cab, saving precious time at the end of the day.
GT3 is capable of evolving in all conditions. Its 700mm of elevation means it can safely negotiate steep slopes, sloping vineyards and stairways. Large wheel motors (optional) enhance the GT3's ability to climb. Its steerable drawbar and row-following sensors make it easy to maneuver in and out of rows. Narrow buckets (optional) allow access to intermediate vines from 1.50 m between rows.
ARC system
The ARC system harvesting principle ensures high quality harvesting and as yet unrivalled handling of the vine. Its exclusive characteristics give you access to an unlimited range of settings, which translates into quick and easy adaptation to any type of vineyard.
EASYclean
On board sorting system allowing perfect harvest quality. The « sorting head's » oscillating motion separates the grapes from vegetal materials. The grapes are stocked in the bins and the vegetal materials are expelled via the sorting table.Ample access available for maintenance.
Fiche technique
GT3
For plantations / vineyards |
Vineyard width from 1.50 m
1.95 m height under frame
|
Engine or linkage |
Direct drawbar attachment to tractor yoke
Integrated hydraulic power unit on 3-point linkage
Hydraulic power unit capacity: 70L
|
Transmission |
700mm/25% tilt correction
Integrated 3-point 70l hydraulic power unit
Return and suction filtration
2-wheel drive
Tires 420/65 R20 (Standard)
500/50 R20 tires (optional)
|
Driving and control |
8.4'' i-Monitor display
Multifunction joystick: tipper management, implement start-up, drawbar management
ISOBUS compatibility: screen and joystick
Automatic transmission management
Automatic drawbar orientation
Automatic height management: obstacle detection
Automatic tilt correction
|
Harvesting module |
14 adjustable shakers
Hydraulic pinch adjustment
2x17 scales
2200mm sealing length
Harvesting at less than 15cm
Conveyor width 320mm
Distance between conveyors 650mm
Adjustable conveyor speed with inversion
Soundproofing on conveyors
Centralized lubrication points
|
Cleaning |
2 bottom vacuums
2 vertical extractors
2 optional top vacuums
Optional EASYclean sorter
|
Bins |
2 x 2000L
Narrow tipper option: 2 x 1600L
Rear discharge
Emptying height 3.00 m
|
